| Rated Output Voltage |
0-30V ( Adjustable ) |
| Rated Output Current |
APS 3005Si : 0-5 A (Adjustable) |
| Rated Output Power |
150W |
| Voltage Accuracy |
± 0.5% Rdg +2bit |
| Current Accuracy |
± 0.5% Rdg +2bit |
| Ripple And Noise |
≤ 3mvrms (Test Conditions 30V / 3A) |
| Load Stability |
≤ 0.3% (Test Conditions 30V / 3A) |
| Digital Display Resolution |
Voltage 0.1V Current 0.01A |
| Protection Methods |
Current Limited Lower Voltage
Short Circuit Protection
Over-Temperature Protection |
| High-pressure Test |
Leakage Current ≤ 1ma (Test Conditions: Input-To-Ground 1700VAC/2s) |
| Insulation Resistance |
Insulation Resistance ≥ 7MΩ (Test Conditions: Input-To-Ground 500VDC/5s) |
| Work Method |
Constant-Current Constant-Voltage |
| Cooling Method |
Strong Wind Cooling |
| Working Environment |
0-40 ℃; Relative Humidity <80% |
| Storage Temperature |
-20-80 ℃ Relative Humidity <80% |
| Size |
260 * 150 * 160 (L * W * H)mm |
